Testing and Perfomance

Abesco FP200 FR Expanding Foam has been tested in various countries in accordance with the methodology and criteria described in:

  • ASTM E814 / UL 1479 (1 & 2 Hr)
  • ASTM E-84 (Flame 10, Smoke 35)
  • ASTM E-662
  • ASTM E-162
  • BS 476- 20 (up to 4 Hr)
  • EN 1366-3 (up to 4 Hr)

Download Information

We provide a variety of documents relating to this product. Please click on the links below to download our documents.

All documents are stored in Adobe Acrobat PDF format and can be viewed by having the Adobe Acrobat reader installed on your computer. If you require further information on this or require to download the software please click the link below.

Most of the information contained on this site is available on our downloadable sales brochure. We also have these available in hard copy and can send them to you on request. Please contact us so we can arrange this.

Click the brochure to download the pdf.

We also have te FP200 Technical Data Sheet and Material Safety Datasheet available for download below



Click the datasheet to download

FP200 Fire Rated Expanding Foam

Abesco FP200 FR Expanding Foam is a single pack Fire Rated polyurethane expanding foam, and is designed to prevent the spread of fire and smoke from one compartment to another through gaps and voids through fire rated walls or floors.

Why use FP200 FR Expanding Foam

  • Extremely versatile solution
  • CFC free
  • Excellent fill capabilities
  • Very easy to install and finish
  • Excellent smoke and draft seal capabilities
  • Sound dampening properties
  • Paintable and stainable
  • Easily trimmed after curing
  • Excellent adhesion to most building substrates
  • Unaffected by moisture or humidity when cured
  • Cures to provide a strong semi-regid seal

Where do I use FP200 FR Expanding Foam

Abesco FP200 FR Expanding Foam is suitable for use in most buildings where a seal is required for through penetrations in fire rated floors and walls.

Typical types of buildings FP200 FR Expanding Foam is commonly used are:

  • Hotels
  • Condominiums
  • Office and Commercial buildings
  • Hospitals
  • Industrial buildings etc

What happens in a fire situation

Under fire conditions Abesco FP200 FR Expanding Foam provides an effective insulating barrier, thereby maintaining the integrity of the wall or floor and preventing the spread of fire from one compartment to another.

Ordering information

Code
Desc
Case Qty
Pallet Qty
Color
Size
20424
24oz FP200 FR Expanding Foam Can
12
12
Pink
24 oz.
20410
10oz FP200 FR Expanding Foam Can
12
12
Pink
10oz.

Technical Information

Application Temperature: Min 41F (5C) Surface
68-77F (20C-25C) Can
Can must be inverted for dispensing
Flammable during dispensing
Tack free time: 5-10 mins*
Cure time: 20-25 mins 1.5" Dia (38mm)*
Hardening time: 1.5 - 2 hrs*
Foam when cured has around 60% closed cell content
Specific gravity: 22-26 kg/m3
Water absorption: max 1% volume
Temp. resistance: -40F to 194F (-40C to 90C)
Tensile strength: 0,071 - 0,076 MPa
Elongation at break: 15 - 20%
Free expansion: 120%

* depending on temperature and humidity

Flame and smoke index: 10 & 35, Class A rating
Flammability class: B1 according to DIN4102 part 1
Storage: 12 to 18 months 5°F to 68°F (10° to 20°C) (ALT-248 for degree symbol)
Higher temperatures can shorten storage life. Must be stored in vertical position (upright)
VOC: VOC: 186.1 g/L in can, less than 2 g/L cured (10+ days)
STC: 38
Dielectric Constant (relative static permittivity) 1.2 R: 7/inch (2.54 cm)
